Features :
• Fully hydraulically controlled German design mechanism.
• Innovative design allows users to choose the force required for opening the door.
• Has two range closing mechanisms in a single sweep.
• Independent speed and force control for both closing ranges.
• Fire tested for 2 hours as per European Standards EN 1154.
• Certified by United Kingdom Accreditation service (UKAS).
• Tested for usage exceeding 3,00,000 Cycles.
• Superior quality silver finish.
Features:
| Product | ODC-203 | ||
|---|---|---|---|
| Technology | Rack & Pinion | ||
| Closing force (EN value) | EN: 2-3 | ||
| Maximum door width | 1200mm | ||
| Maximum door weight | 65Kg | ||
| Design | Reversible non-handed design | ||
| Power transmission | Track arm with U Channel | ||
| Closing speed range | 120-15 degrees | ||
| Latching speed range | 15-0 degrees | ||
| Latching action | Self Adjust | ||
| Hold Open | Optional(70-120) Degrees | ||
| Length | 232mm | ||
| Width | 33mm | ||
| Height | 57mm | ||
| Installation Possibilities | Door leaf & transom | ||
| Cycle Tested | 5 Lac |
