Features :
• German design-high quality,precision machined mechanism.
• Internal mechanism components utilizing heat treated high grade alloy steels & ball bearing for optimum efficiency.
• High grade cast iron body housed within a galvanized steel box.
• Cover plate made of certified stainless steel grade 304 for superior rust prevention.
• German standard machine oil and sealed rings for longer life.
• Hinge mechanism totally immersed in high grade hydroulic fluid.
• Built in pressure relief valve protects the closer form rough use.
• Designed for smooth functioning within wide temperature ranges.
• Ideal for use in any kind of door.
• SINGLE CYLINDER cam action floor hinge.
• Cam action floor Hinge with closing force EN2.
• Maximum opening angle 90° both sides.
• Maximum door weight 70 Kg.
• Maximum door width 900 mm.
• Specially designed for WOODEN AND ALUMINUM DOOR.
• RFS-TP and RFS-BP included in set.
